3 or 4 axis CNC machining center for heavy duty application, designed to work on extruded aluminum, light alloy and steel materials.
The gantry type structure guarantee stability and tolerances especially for heavy duty work either on Aluminum or Steel.
• 8000 mm (315″) machining length • 650 x 300 mm (25.6″ x 11.8″) machinable cross-section • 8.5kw – 10kw spindle (optional) • n. 12 tools magazine
3 or 4 axis CNC machining center designed to work on extruded aluminum, light alloy, PVC and light steel materials.
Wide clamping capacity, the machine can allocate a full door frame or garage sandwich panel and machine all in one.
• 8000 mm (315″) machining length • 650 x 300 mm (25.6″ x 11.8″) machinable cross-section • 5.5kw / 7.5kw spindle (optional) • n. 8 tools magazine
Ultra high speed 4 axis CNC machining center designed to work on extruded aluminum, light alloy, PVC and light steel materials.
• 8000 mm (315″) machining length • X axis speed 150 m/min (5905.5 inches/min) • 250 x 200 mm (9.8″ x 7.9″) machinable cross-section • n. 11 tools magazine • 8.5kw spindle
4 axis CNC machining center designed to work on extruded aluminum, light alloy, PVC and light steel materials.
• 4000 mm (157.48″) machining length • 250 x 200 mm (9.8″ x 7.9″) machinable cross-section • 6kw – 8.5kw spindle (optional) • n. 10 tools magazine
• 4000 mm (157.48″) machining length • X axis speed 150 m/min (5905.5 inches/min) • 250 x 200 mm (9.8″ x 7.9″) machinable cross-section • n. 10 tools magazine • n. 10 tools magazine• n. 10 tools magazine • 8.5kw spindle
• 3200 mm (126″) machining length • Automatic setting of the clamps, positioned by spindle • 250 x 170 mm (9.8″ x 6.7″) machinable cross-section • 3.8kw – 5.5kw spindle (optional) • n. 5 tools magazine
3+1 axis CNC machining center designed to work on extruded aluminum, light alloy, PVC and light steel materials.
• 2900 mm (114″) machining length • Manual setting of the clamps, with laser indicator • 250 x 170 mm (9.8″ x 6.7″) machinable cross-section • 3.8kw – 5.5kw spindle (optional) • n. 5 tools magazine
Enclosed 5 Axis CNC machining center, designed to work on Aluminum extrusion profile, Light alloys, PVC and Steel materials.
• 8000 mm (315″) machining length • 300 x 230 mm (11.8″ x 9″) machinable cross-section • 10kw spindle • n. 12 tools magazine • n. Saw blade max diam 300 mm (11.8″)
5 axis CNC machining center designed to work on extruded aluminum, light alloy and steel materials. The gantry type structure guarantee stability and tolerances especially for any sector, the ideal machine for curtain walls and window walls profiles.
• 8000 mm (315″) machining length • 500 x 300 mm (19.7″ x 11.8″) machinable cross-section • 10kw spindle • n. 12 tools magazine • n. Saw blade max diam 450 mm (17.71″)
5 axis CNC machining center designed to work on Aluminum extrusion profile, Light Alloys and Steel materials for a large variety of industries and manufacturing sector.
The gantry type structure guarantee stability and tolerances especially for heavy duty work either on Aluminium or Steel.
• 8600 mm (340″) machining length • 550 x 300 mm (21.6″ x 11.8″) machinable cross-section • 12kw spindle • n. 18 tools magazine • n. Saw blade max diam 500 mm (19.68″)
Flat bed 3 axis CNC machining center designed to work on composit panels, ACM panels, auminium plates, and acrlic panels.
• 4000×2000 mm (157.48″ x 78.74″) machining capacity • 6000×2000 mm (236.22″ x 78.74″) machining capacity • n. 2 or 3 vacum pumps of 5,5 kw each • 7.5kw spindle • n. 12 tools magazine
No Product to show in this category.
• Machining center designed for producing components from a Aluminum extruded bar. • Automated sawing and machining line, ideal for producing short components • The possible machining operations are milling, drilling, tapping and cutting. • Useful stroke X = 2000 mm (78.74″); Y = 1050 mm (41.33″); Z = 500 mm. (19.68″) • N. 12 tool magazine • Cutting unit with blade Ø 500 mm (19.68″)
• Fabrication center for windows doors / curtain walls / window walls system • 11 Axis CNC • n. 4 spindle mounted on rotating ring (up to 6 spindles – optional) • Sawblade diameter 550 mm (21.65″) • Cutting capacity L 250 (9.84″) • Cutting capacity H 150 (5.90″)
Double mitre saw with a fixed unit on the left and the other one movable.
• 7″ Touch screen HMI • Automatic positioning of the movable unit • Pneumatic tilting of the heads (90°, 45° or 22,5°) • Ø 500mm (19.6″) saw blade • Available length: 4000mm (157.48″), 5000mm (196.85), 6000mm (236.22)
• Magelis 10″ touch screen HMI • Automatic positioning of the movable unit • Pneumatic tilting of the heads (90°, 45° or 22,5°) • Ø 500mm (19.6″) saw blade • Available length: 4000mm (157.48″), 5000mm (196.85), 6000mm (236.22)
• Magelis 10″ touch screen HMI • Automatic positioning of the movable unit • Servo blade tilting of the heads (any degrees between 90° – 22,5°) • Ø 500mm (19.6″) saw blade • Available length: 4000mm (157.48″), 5000mm (196.85), 6000mm (236.22)
• Magelis 10″ touch screen HMI • Automatic positioning of the movable unit • Pneumatic tilting of the heads (135°, 90°, 45° or 22,5°) • Ø 500mm (19.6″) saw blade • Available length: 4000mm (157.48″), 5000mm (196.85), 6000mm (236.22)
• Magelis 15″ touch screen HMI • Automatic positioning of the movable unit • Servo blade tilting of the heads (any deg between 135° – 22,5°) • Ø 500mm (19.6″) saw blade • Available length: 4000mm (157.48″), 5000mm (196.85), 6000mm (236.22)
• Magelis 10″ touch screen HMI • Automatic positioning of the movable unit • Pneumatic tilting of the heads (90°, 45° or 22,5°) • Ø 550mm (21.65″) saw blade • Available length: 4000mm (157.48″), 5000mm (196.85), 6000mm (236.22)
• Magelis 10″ touch screen HMI • Automatic positioning of the movable unit • Pneumatic tilting of the heads (135°, 90°, 45° or 22,5°) • Ø 550mm (21.65″) saw blade • Available length: 4000mm (157.48″), 5000mm (196.85), 6000mm (236.22)
• Magelis 15″ touch screen HMI • Automatic positioning of the movable unit • Servo blade tilting of the heads (any deg between 135° – 22,5°) • Ø 550mm (21.65″) saw blade • Available length: 4000mm (157.48″), 5000mm (196.85), 6000mm (236.22)
Double mitre saw with upstroke blade feed with radial and pivoting motion
• Magelis 15″ touch screen HMI • Automatic positioning of the movable unit • Servo blade tilting of the heads inwards (any deg 90° – 45°) • Ø 600mm (23.62″) saw blade • Available length: 5000mm (196.85), 6000mm (236.22)
Compound 5 AXIS double mitre saw with upstroke blade feed with radial and pivoting motion
• Magelis 15″ touch screen HMI • Automatic positioning of the movable unit • Servo blade tilting of the heads inwards (any deg 90° – 45°) • Servo blade rotation of the heads (any deg 135° – 22.5°) • Ø 600mm (23.62″) saw blade • Available length: 5000mm (196.85), 6000mm (236.22)
Double mitre saw for STEEL and stainless steel profile
• Magelis 15″ touch screen HMI • Automatic positioning of the movable unit • Servo blade tilting of the heads inwards and outwards (any deg 135° – 45°) • Ø 400mm (15.74″) saw blade • Available length: 5000mm (196.85)
Machining centers, cutting machines, handling and customised systems
for the Aluminum industry
MC307 FALCON Ultra high speed 4 axis CNC machining center designed to work on extruded Aluminum, Light Alloys, PVC and light Steel materials.
TDC622 EDGEMASTER This model is an up-stroke double head compound miter saw with powered movement of the right head by means of a DC servomotor.
MC302 GEOS-5 5 axis CNC machining center designed to work on Aluminum extrusion profile, Light Alloys and Steel materials for a large variety of industries and manufacturing sector. The gantry type structure guarantee stability and tolerances especially for heavy duty work either on Aluminum or Steel.
MC 316 Fabrication center has been designed for automatic milling, drilling, tapping and cutting operations on aluminum profiles. The unit consists of a loading magazine, servo material pusher, machining station, cutting station, and motorized unloading table.
The superb quality, functionality and reliability of MECAL MACHINERY products is guaranteed by an advanced engineering and design department managed by dynamic and highly qualified personnel. The presence of a dedicated, full-time, in-house engineering and design department represents a key added value for MECAL MACHINERY’s customers.
We will process your profile in Aluminium , Light Alloys, Steel, PVC
Windows & Doors either in Aluminium , PVC or Steel has always been the sector where our machines can make a big difference: cutting/machining/handling and much more...
Aluminium is becoming very common in the automotive industry.
MECAL has a soution for frame/chassis, bumpers, side foot step , battery pack for electric vehicles and etc etc.
As Automotive industry, also this sector of Truck and Trailer became very important for our machines and equipments, we have great solution for it!
Aluminium, Light Alloys and Steel is common in the furniture industry: kitchen designer, wardrobes manufacturer, office partition maker, tables, etc etc...
We have the right machines!
Curtain Walls or Window Walls is one of the main sector of our business, we have many solutions for cutting machines, machining centers and customised systems
We started entering into Aerospace industry, supplying machines for some airplane components and even more for airport construction and handling equipment.
Our 5 Axis machining centers are the right choice for the manufacturing of coaches and wagons and all the inside structures.
Get in touch with us!
We call Industrial sector, all those industries where there is an important use of Aluminium extrusion profile, like Lightning, Elevators, Handling, Advertising signs and much more...
